Sony Progressive Scan System CCD
Product name |
Image |
Filter mounted |
Effective Pixels (H x V) |
Package |
Pins |
Recommended timing pulse generator |
2/3 |
Primary color mosaic |
1392 x 1040 |
Ceramic DIP |
20 |
- |
|
2/3 |
Monochrome |
1392 x 1040 |
Ceramic DIP |
20 |
||
1/1.8 |
Primary color mosaic |
1688 x 1248 |
Plastic DIP |
20 |
- |
|
1/1.8 |
Monochrome |
1688 x 1248 |
Plastic DIP |
20 |
- |
|
1/2 |
PALPrimary color mosaic |
659 x 494 |
Cer-DIP |
22 |
||
1/2 |
Monochrome |
659 x 494 |
Cer-DIP |
22 |
||
1/2 |
Primary color mosaic |
782 x 582 |
Cer-DIP |
22 |
||
1/2 |
Monochrome |
782 x 582 |
Cer-DIP |
22 |
||
1/2 |
Primary color mosaic |
1392 x 1040 |
Cer-DIP |
20 |
||
1/2 |
Monochrome |
1392 x 1040 |
Cer-DIP |
20 |
||
| 1/3 |
Primary color mosaic |
1077 x 788 |
Plastic DIP |
16 |
- |
|
1/3 |
Monochrome |
1077 x 788 |
Plastic DIP |
16 |
- |
|
1/3 |
PALPrimary color mosaic |
659 x 494 |
Plastic DIP |
16 |
||
1/3 |
Monochrome |
659 x 494 |
Plastic DIP |
16 |
||
1/3 |
PALPrimary color mosaic |
1296 x 966 |
Plastic DIP |
20 |
||
1/4 |
Primary color mosaic |
659 x 494 |
Plastic DIP |
14 |
||
1/4 |
Monochrome |
659 x 494 |
Plastic DIP |
14 |
